Designing a notation

Abstract

The original design of ixml did not focus on converting text files into particular XML document types, but converting them to some XML document type for further transformation. However, the other direction is possible: if you have a particular document type, you can design a textual notation for it. This paper treats a particular use case, in order to reveal some of the options and techniques available to designers of such a notation.

Keywords: Markup, ixml, Invisible Markup, notations, parsing, XML, design, XForms.

Abstraction and Extraction

ixml's original design: allow non-marked-up textual documents to be treated as if they were XML documents with markup.

Part of a progression of document abstractions:

Originally (proprietary) documents needed each program to have have a special input routine for that format, with knowledge of the underlying structure;
Markup made the structure explicit, enabling all data in all programs to be read by a single input routine;
Marked-up data would often include presentation markup: style sheets extracted the presentation into a separate file, usable for a whole class of documents;
ixml abstracts even the markup out of the documents into a separate file, similarly usable for a whole class of documents.

The Problem

The design of ixml was not to convert textual documents to any particular XML document types, but just to get a textual document into an XML form that could later be refined as necessary using existing XML tools.

You are unlikely to be able to target an existing document type, only:

produce an intermediate document type with ixml
transform that to the target document type with other tools.

The Reverse Approach

However it is possible to work in the other direction:

Given an existing XML document type, you can design a textual representation for it for use with ixml.

People seem to prefer authoring flat textual documents, because they can see the structure unaided, and find the need to add markup a distraction.

Example: Markdown, a flat version of (X)HTML.

We are going to go from

XForms Example
style app.css

data admin.xml
   relevant message .!=''
   type weight integer
   constraint weight .>0
   type weight/@date date

data #weights weights.xml

submission #save put:instance('weights') to:weights.xml replace:none {
   FAILURE setvalue message "Save failed"
   SUCCESS setvalue message ""
}

input weight "Weight" incremental
output.error message "Error"

trigger "Save" {
   DOMActivate? {
      setvalue weight/@date local-dateTime()
      insert weight into:instance('weights')/weight
      submit
   }
}

To

<html xmlns='http://www.w3.org/1999/xhtml'>
   <head>
      <title>XForms Example</title>
      <link href='app.css' type='text/css' rel='stylesheet'/>
      <model ev:event='xforms-ready'>
         <instance src='admin.xml'/>
         <bind ref='message' relevant='.!=&apos;&apos;'/>
         <bind ref='weight' type='integer'/>
         <bind ref='weight' constraint='.>0'/>
         <bind ref='weight/@date' type='date'/>
         <instance id='weights' src='weights.xml'/>
         <setvalue ref='weight/@date' value='local-dateTime()'/>
         <submission id='save' method='PUT' ref='instance(&apos;weights&apos;)' resource='weights.xml' replace='none'>
            <action ev:event='xforms-submit-error'>
               <setvalue ref='message'>Save failed</setvalue>
            </action>
            <action ev:event='xforms-submit-done'>
               <setvalue ref='message'/>
            </action>
         </submission>
      </model>
   </head>
   <body>
      <group xmlns='http://www.w3.org/2002/xforms'>
         <input ref='weight'>
            <label>Weight</label>
         </input>
         <output class='error' ref='message'>
            <label>Error</label>
         </output>
         <trigger ev:event='DOMActivate'>
            <label>Save</label>
            <insert origin='weight' ref='instance(&apos;weights&apos;)'/>
            <send/>
         </trigger>
      </group>
   </body>
</html>

The Basics

For an existing XML document type, the structure has already been specified: there are no decisions to be made.

For instance, the top level ixml rules for Markdown must be html, head, and body, since they have to match the final target structure.

Similarly, for XForms, the overall structure of the rules can be determined directly from the XForms schema.

Top-level structure

At the top level we get the ixml rules from the XForms schema:

         model: (instance; bind; action; submission)*.
      -Content: Controls.
     -Controls: Core-Controls; group; switch; repeat.
-Core-Controls: input; secret; textarea; output; upload;
                range; trigger; submit; select; select1.

(Rule names with an initial lower-case letter are used for actual elements that will occur in the output; names with an initial capital are other rules).

Host Language

XForms wasn't designed to be a standalone language, but one embedded in other languages, so we need to specify a top-level structure in a host language, in this case XHTML:

html: head, body.

where head contains the models, and body contains the content. For instance:

head: title, Style*, model+.
body: Content.

Positioning

For instance, since the title is the first item in the head, we can just use positioning and require that the first line be the title of our XForm:

title: ~[#a]+, nl.

The rule for nl requires a newline, and allows extra optional trailing space:

-nl: -#a, s?.

The rule for s is to allow trailing space, but we will also use it where spacing is required, not just optional:

-s: -[" "; #9; #a]+.

Using Extra Characters

For styling we use extra characters to identify the input, in this case the word "style".

XForm Example
style app.css

Although it would also be possible to allow embedded CSS, to keep it simple we will just use html link elements:

          -Style: -"style", s, link.
            link: href, Style-type, Style-rel.
           @href: URL.
@Style-type>type: +"text/css".
  @Style-rel>rel: +"stylesheet".
            -URL: [L;"0"-"9"; ":/@.~#?"]+.
                  {A simple version for now}

This requires a URL, and adds two other attributes to the output.

Renaming

Note how ixml renaming has been used, and the use of insertions to provide fixed content:

@Style-type>type: +"text/css".

Renaming is not yet officially part of ixml, but is in the evolving future specification and in all implementations.

So a flat XForm beginning

XForm Example
style app.css

gives an output that starts

<html>
  <head>
    <title>XForm Example</title>
    <link href='app.css' type='text/css' rel='stylesheet'/>

Namespaces

How to deal with namespaces is not yet resolved in the working group.

Although XML namespace declarations look like attributes, they have a different semantic interpretation because they begin with the characters xmlns.

An Approach to Namespaces in ixml

Since ixml is just producing an XML document, it can use the same approach: treating something that looks like an attribute as a namespace declaration if it starts with the letters xmlns.

For implementations that produce textual output, this adds no extra processing; for implementations that go directly to an XML internal form, the namespace declarations have to be recognised and handled appropriately.

Example

Accepting this, we can redefine the html rule to include a namespace in this way:

           html: xhtml-ns, head, body.
@xhtml-ns>xmlns: +"http://www.w3.org/1999/xhtml".

which will give

<html xmlns='http://www.w3.org/1999/xhtml'>

Content

We can do the same to enclose the XForms controls in the body in an element that declares the namespace:

          body: Content.
 Content>group: xf-ns, Controls.
  @xf-ns>xmlns: +"http://www.w3.org/2002/xforms".

which will give

<body>
   <group xmlns='http://www.w3.org/2002/xforms'>

Controls

The controls come straight from the XForms schema:

     -Controls: Control*.
      -Control: CoreControl; group; switch; repeat.
  -CoreControl: input; secret; textarea; output; upload;
                range; trigger; submit; select; select1.

Core Controls

Most controls have a number of required parameters, and a number of optional ones. For instance, consider input:

<input ref="person/@age">
   <label>Age</label>
</input>

We can define this using a leading keyword and then positioning:

input person/@age "Age"

like this:

input: -"input", s, ref, label.
 @ref: XPath.
label: -'"', ~['"'; #a]*, -'"', s?.
XPath: [L; "0"-"9"; "/:@[]()+-*'><!=."]+, s?.
        {A simple version for now}

Incremental

There's one other useful attribute for several controls, and that is incremental="true" that specifies that the control activates for every character typed.

Since incremental="false" is the default, we don't have to specify it, so you can write:

input person/@age "Age" incremental

by changing the rule for input to:

       input: -"input", s, ref, label, incremental?.
@incremental: -"incremental", +"true", s?.

so that we get

<input ref='person/@age' incremental='true'>
   <label>Age</label>
</input>

Common Attributes

Nearly all elements in XForms can have certain common attributes, in particular class for presentation purposes, and id for identification.

<output class="error" id="out1" ref="message">
   <label>Error</label>
</input>

One option would be to give these a keyword to identify them:

output class:error id:out1 message "Error"

Alternative approach

Another way would be to use the same notation as used in CSS:

output.error #out1 message "Error"

like this:

output: -"output", class?, id?, ref, label.
@class: -".", name.
   @id: -"#", name.
 -name: [L], [L; "0"-"9"]+, s?.

Reuse

We can group them together as Common attributes:

-Common: class?, id?.

and use them everywhere:

output: -"output", Common, ref, label.

The Model

Going back to the definition of the head

head: title, Style*, model+.

we still have to define the model.

Defining the model

For instance:

model: "model", s, id?,
       (instance; bind; Action; submission)*.

with

instance: -"data", s, id?, src.
    @src: URL.

and

bind: -"properties", s, ref, Property+.

and

  -Property: type; constraint; relevant; required; readonly.
      @type: -"type:", s?, name.
@constraint: -"constraint:", s?, Expression.
-Expression: XPath.

(we'll come back to Action and submission later).

Example model

model
   data people.xml
   properties person/@age type:integer constraint:.>0

As you can see, we are not obliged to use the same keywords in the input as the elements in the output.

So in this case for example we have replaced the somewhat technical-sounding instance with the more general data, and bind with properties.

Alternative Approach for Properties

To distinguish the various types of property in a bind, we have used keywords. However another approach would be to give them each a separate definition:

model
   data people.xml
   type person/@age integer
   constraint person/@age .>0

like this:

 -Model-content: (instance; Bind; Action; submission)*.
          -Bind: Type; Constraint; Relevant; Required; Readonly.
      Type>bind: -"type", s, ref, s, type.
          @type: name.
Constraint>bind: -"constraint", s, ref, constraint.
    @constraint: Expression.

etc., yielding

<model>
   <instance src='people.xml'/>
   <bind ref='person/@age' type='integer'/>
   <bind ref='person/@age' constraint='.>0'/>

Alternative Approach to Models

Nearly all XForms applications have only a single model, so an alternative approach is to define models so that in the simple (usual) case you don't have to declare a model at all, only when there is more than one:

               head: title, Style*, Models.
            -Models: Single-model; model+.
-Single-model>model: Model-content.
              model: -"model", s, id?, Model-content.

allowing in the simple case:

XForms Example
style app.css
data people.xml
   type person/@age integer
   constraint person/@age .>0

Container Controls

Some controls can contain other content, and be nested, the simplest case being group:

<group>
   ...controls...
</group>

So we have a design a syntax for this style of control. Options could include

group:
   ...
:group

group
   ...
/group

group{
   ...
}group

or indeed just

group {
   ...
}

Non-Container Controls

Controls that are not principally containers, may also contain content:

<input ref="person/@age">
   <label>Age</label>
   <dispatch name="CHANGED" targetid="m" ev:event="xforms-value-changed"/>
</input>

so it would be good if any syntax we choose be consistent with these cases. For instance:

input person/@age "Age" {
   dispatch CHANGED m xforms-value-changed
}

and

input person/@age "Age" {
   hint "An integer"
}

Blocks

We can do this by declaring a block:

-Block: -"{", s?, Controls, "}", s?.

and then define group as:

group: -"group", Common, ref?, label?, Block.

which requires a block, and

input: -"input", Common, ref, label, incremental?, Block?

where it is optional.

Actions

XForms actions respond to asynchronous events.

We have already seen one above, dispatch.

Each has its own attributes, plus optionally an event being responded to.

Example action

For instance within a submission, a setvalue might look like this.

<setvalue ref="message"
           ev:event="xforms-submit-error">Failed</setvalue>

We could represent this directly as

setvalue message "Failed" xforms-submit-error

however, setvalue can also calculate a value

<setvalue ref="count" value=".+1" ev:event="DOMActivate"/>

Luckily these two cases are syntactically distinguishable, so we can define it as

         setvalue: -"setvalue", s, ref, (string; value), event.
           @value: expression.
@event>"ev:event": name.

Grouping Actions

There is a grouping element for several actions, called action:

<action ev:event="xforms-ready">
   <setvalue ref="date" value="local-dateTime()"/>
   <dispatch name="TICK" targetid="clock"/>
</action>

We can treat that in the same way that we treated group earlier:

      action: -"action", s, event, ActionBlock.
-ActionBlock: -"{", s?, Action*, -"}", s?.
     -Action: toggle; setvalue; dispatch; action. {etc}

allowing

action xforms-ready {
   setvalue date local-dateTime()
   dispatch TICK clock
}

Alternative Approach to Actions

However, we are not confined to doing it this way. Another approach would express it as:

xforms-ready? {
   setvalue date local-dateTime()
   dispatch TICK clock
}

defined by:

action: event, -"?", s?, (Action; ActionBlock).

which would also allow:

DOMActivate? setvalue count .+1

Submission

HTTP submission is complicated, and so the XForms submission element is as well.

Therefore we will only address a subset of its features here.

Example Submission

A typical submission looks like this:

<submission id="save" method="put" ref="instance('data')"
            resource="data.xml" replace="none">
    <setvalue ref="message" ev:event="xforms-submit-error"
       >Save failed</setvalue>
    <setvalue ref="message" ev:event="xforms-submit-done"/>
</submission>

which could be represented like this:

submission #save put:instance('data') to:data.xml
           replace:none
{
   xforms-submit-error? setvalue message "Save failed"
   xforms-submit-done? setvalue message ""
}

Dealing with submission failure

However, this is such a common pattern, it might be worth enforcing the handling of the return events, something like this:

submission #save put:instance('data') to:data.xml
           replace:none
{
   FAILURE setvalue message "Save failed"
   SUCCESS setvalue message ""
}

along these lines:

        submission: -"submission", Common, s, Method,
                      resource, replace?, SubBlock.
           -Method: PUT; GET; POST; DELETE; HEAD.
              -PUT: method-put, ref.
              -GET: method-get, ref.
@method-put>method: -"put:", +"PUT".
@method-get>method: -"get:", +"GET".

etc.

Submission block

A Submission Block then allows the success and failure parts in either order:

            -SubBlock: -"{", s?,
                      (SUCCESS, FAILURE;
                       FAILURE, SUCCESS), -"}", s?.
       SUCCESS>action: -"SUCCESS", s?, evSuccess,
                         (Action; ActionBlock).
@evSuccess>"ev:event": +"xforms-submit-done".
       FAILURE>action: -"FAILURE", s?, evFailure,
                         (Action; ActionBlock).
@evFailure>"ev:event": +"xforms-submit-error".

giving an output like this:

<submission id='save' method='PUT' ref='instance(&apos;data&apos;)' resource='data.xml' replace='none'>
   <action ev:event='xforms-submit-error'>
      <setvalue ref='message'>Save failed</setvalue>
   </action>
   <action ev:event='xforms-submit-done'>
      <setvalue ref='message'/>
   </action>
</submission>

Example XForm

XForms Example
style app.css

data admin.xml
   relevant message .!=''
   type weight integer
   constraint weight .>0
   type weight/@date date

data #weights weights.xml

submission #save put:instance('weights') to:weights.xml
            replace:none
{
   FAILURE setvalue message "Save failed"
   SUCCESS setvalue message ""
}

input weight "Weight" incremental
output.error message "Error"

trigger "Save" {
   DOMActivate? {
      setvalue weight/@date local-dateTime()
      insert weight into:instance('weights')/weight
      submit
   }
}

Resulting XML

<html xmlns='http://www.w3.org/1999/xhtml'>
   <head>
      <title>XForms Example</title>
      <link href='app.css' type='text/css' rel='stylesheet'/>
      <model ev:event='xforms-ready'>
         <instance src='admin.xml'/>
         <bind ref='message' relevant='.!=&apos;&apos;'/>
         <bind ref='weight' type='integer'/>
         <bind ref='weight' constraint='.>0'/>
         <bind ref='weight/@date' type='date'/>
         <instance id='weights' src='weights.xml'/>
         <setvalue ref='weight/@date' value='local-dateTime()'/>
         <submission id='save' method='PUT' ref='instance(&apos;weights&apos;)' resource='weights.xml' replace='none'>
            <action ev:event='xforms-submit-error'>
               <setvalue ref='message'>Save failed</setvalue>
            </action>
            <action ev:event='xforms-submit-done'>
               <setvalue ref='message'/>
            </action>
         </submission>
      </model>
   </head>
   <body>
      <group xmlns='http://www.w3.org/2002/xforms'>
         <input ref='weight'>
            <label>Weight</label>
         </input>
         <output class='error' ref='message'>
            <label>Error</label>
         </output>
         <trigger ev:event='DOMActivate'>
            <label>Save</label>
            <insert origin='weight' ref='instance(&apos;weights&apos;)'/>
            <send/>
         </trigger>
      </group>
   </body>
</html>

Conclusion

This is not a complete or final design of a flat version of XForms, and there are still many details that need to be completed.

Designing a text notation for an XML Document type is an interesting, even fun, exercise.

While the overall structure of the document is already fixed, the designer has a lot of freedom in using keywords, extra characters, or positioning, to identify syntactic forms.

While at first unexpected, there is also a lot of freedom in the choice of keywords and similar, that are not required to match the terminology used in the document type.

Designing a Notation Using ixml

Abstract

Contents

Abstraction and Extraction

The Problem

The Reverse Approach

The Design Process

We are going to go from

To

Giving

Warning

The Basics

Top-level structure

Host Language

Recognising Input

Positioning

Using Extra Characters

Renaming

Namespaces

An Approach to Namespaces in ixml

Example

Content

Controls

Core Controls

Incremental

Common Attributes

Alternative approach

Reuse

The Model

Defining the model

Example model

Alternative Approach for Properties

Alternative Approach to Models

Container Controls

Non-Container Controls

Blocks

Actions

Example action

Grouping Actions

Alternative Approach to Actions

Submission

Example Submission

Dealing with submission failure

Submission block

Example XForm

Resulting XML

Resulting App

Conclusion
